Tube Straightener, Cut & End Form Machine, Burr Oak , 1.125"

Ref # 11119-HK

Click on photo to enlarge

YEAR: 2014


-Model: STCO-M5-1119 RH

-Capacity: 0.125" - 1.125" Diameter
-Minimum Length of Cut: 0.750"
-Maximum Length of Cut: Limited by Length of Runout Table
-Cutoff: Standard Burrless
-Hitch Feed: Tandem Belt Feed 36" BHD50
-Straightener: Reverse Plane Straightener with Sizing, Large Capacity
-Pull Apart
-End Form 2-Hit

Includes the following:

-Coil Stand: Powered Horizontal Coil Stand

-Runout Table: 24' Table with Hold Gate

-Electrical:
480 Volt, 3 Ph, 60 Hz.
Control: 110 / 24

Extra Options:
Powered Tube Puller
Metric Machine
Allen Bradley Controller

-Tooling: Steel (Cu Flash): 0.188" Dia. x 0.025" Wall
0.157" (4mm) Dia.

-Operators Manual Included.

-Removed and in storage; Toledo, OH.
